額定電流(rating)：3A-60A

輸入電壓(Input Power)：125VAC/250VAC/24/32VDC 50-60Hz

耐電壓強度(Withstand voltage strength)：1500VAC/1min,漏電電流≤0.5mA

(1500VAC/min,the leaked current is less than≤0.5mA)

絕緣電阻(Insulation Resistance)：500VDC 1Min≥100MΩ

額定短路能力(Rated short-circuit capacity)：125VAC/1000A，250VAC/1000A

額定通斷能力(Rated breaking capacity)：6倍額定電流

（6 times rated current)

復位方式(Reset)：自動復位(Auto Reset)

復位時間(Reset Time)：60s”內回復(Within 60s”)
